Darabár legkevesebb 5 darab vásárlása esetén! Minimum vásárlási mennyiség 5 darab!
| Product |
Instant On AP22 |
| Part Number |
R4W01A
R4W02A
R4W03A
R4W04A
R4W05A
R6R77A
R6R78A
R6R79A
R6M49A
R6M50A
R6M51A
S0G19A
S0G23A |
| Description |
Indoor, dual radio, 5 GHz 802.11ax 2x2 MIMO and 2.4 GHz 802.11ax 2x2 MIMO |
| Product Type |
Access Point |
| Ports |
1x GE, with PoE-in support (802.3af) |
| Number of Radios |
2 |
| Wi-Fi Alliance Certification |
Wi-Fi Alliance certified (WFA) 802.11ax with (Wi-Fi 6), WPA2, WPA3 |
| Performance |
|
| Memory and Processor |
N/A |
| MAC Address Table Size |
N/A |
| Electrical Characteristics |
|
| Maximum Heat Dissipation |
N/A |
| Maximum Power Rating |
10.1W (PoE), 8.8W (DC) |
| Power Inputs |
Uplink Gigabit Ethernet port, with PoE-in support (802.3af)
DC power connector (12V) |
| Antenna Connector |
N/A |
| Antenna |
Down-tilt omni-directional antennas for 2x2 MIMO with peak antenna gain of 4.3dBi in 2.4GHz and 5.6dBi in 5GHz (of the effective, combined pattern for both antennas in each band). |
| Number of Internal Antennas |
N/A |
| Number of External Antennas |
N/A |
| Notes |
N/A |
| Physical Characteristics |
|
| Dimensions |
160 mm (W) x 160 mm (D) x 37 mm (H)
6.29” (W) x 6.29” (D) x 1.46” (H) |
| Weight |
500 g/17.64 oz |
| Additional Details |
|
| MIMO |
2x2 |
| Spatial Streams |
N/A |
| Notes |
N/A |
